Operators: Finish 7 Point Container Maintenance Checklist in One Shift

Before stuffing or handling any unit, perform a 7-point inspection covering the front wall, both sides, floor, roof, doors, and undercarriage, and tag any unsafe container out of service immediately. This baseline check draws on CTPAT guidance for security and OSHA standards for handling safety. If a defect compromises structure or seal integrity, do not load the container: repair it first or pull it from the rotation.

TL;DR:

• Most safety and security failures involve corrosion, structural cracks, or door lock issues that require immediate repair or replacement before loading.
• Regular inspections should be performed before every stuffing, with monthly, quarterly, and annual checks addressing moisture, rust, and foundation issues.
• Proper documentation of defects, repairs, and seal verification ensures compliance and smoother audits, with records kept for at least a year.
• Major structural defects such as bent corner posts or large holes mandate pulling containers out of service and scheduling professional repairs.
• Non-structural issues like gasket wear or surface rust can often be repaired on-site, but compromised load-bearing parts generally require unit replacement.

Table of Contents

• Step-by-step container maintenance and inspection checklist
• Routine maintenance schedule and intervals
• Safety, regulatory, and out-of-service criteria
• Rust, roof, floor, and door maintenance tasks
• Documentation, seal control, and maintenance records
• Conexwest support options: repair or replace
• Fitting the checklist into a single shift
• Sources
• FAQ

Step-by-step container maintenance and inspection checklist

A 7-point inspection takes a few minutes per unit and should happen before every stuffing cycle, not just during scheduled maintenance. Work the same order every time so nothing gets skipped under pressure.

1. Front wall: Check for dents, holes, or repair patches that break the surface. Light surface rust passes; any daylight showing through fails.
2. Left side: Look along panel seams and rivets for separation or bulging. A wall that flexes when pushed needs further review.
3. Right side: Repeat the same check, paying attention to the bottom rail where splash and road grime collect.
4. Floor: Walk the full length, checking for soft spots, warping, or oil saturation. Plywood that gives underfoot fails.
5. Ceiling and roof: Inspect from inside for light penetration and from outside for standing water or dents that pool rain.
6. Doors, inside and outside: Open and close both doors fully. Locking bars should engage without force, and gaskets should sit flush.
7. Outside and undercarriage: Check cross members, corner castings, and the understructure for cracks, corrosion, or missing hardware.

Seal verification happens at the same time. Record the seal number against the container ID before loading, confirm the seal meets ISO 17712 high-security standards, and photograph it if your yard supports that step.

If a point fails:

• Tag the container with a clear “out of service” marker visible from the yard aisle.
• Notify the maintenance lead or supervisor before the shift ends.
• Log the defect with container ID, location, and a one-line description.
• Route the unit to repair or replacement rather than re-staging it for load.

Pro Tip: Keep a laminated 7-point card clipped to a clipboard at the gate. Checkers move faster when they’re not recalling the sequence from memory.

Routine maintenance schedule and intervals

A fixed schedule catches problems before they turn into downtime. Pair it with the pre-stuffing check rather than replacing it.

• Monthly: Exercise all doors fully, inspect gaskets for cracking, and check interior walls for condensation or moisture staining.
• Quarterly: Clear roof debris, grease hinges and locking gear, and clear vents of dust or nesting material.
• Annually or every five years: Touch up exterior paint where rust has started, check that the container sits level on its foundation, and schedule a professional inspection or full repaint for units showing wider wear.

Monthly checks catch moisture and door issues early, while the longer intervals address wear that builds slowly, like coating breakdown or foundation settling.

Safety, regulatory, and out-of-service criteria

OSHA’s rules for intermodal terminals require visual inspection before handling, with unsafe containers identified, removed from service, and repaired before they return to use. Lifting gear, twistlocks, and interbox connectors need the same scrutiny since cracked or worn hardware is a common cause of handling accidents.

CTPAT’s 7-point checklist doubles as a security control, not just a structural one: seal control and verified locking mechanisms matter as much as sound walls. The IMO’s Convention for Safe Containers places the maintenance burden on owners, who must keep units in condition that meets periodic safety approval for international transport.

Pull a container out of service immediately when you find:

• A cracked or bent corner post or casting.
• A hole or tear large enough to let in light or water.
• A door that won’t fully lock or seal.
• Corrosion that has eaten through a structural member rather than just the surface coating.

IMO’s Convention for Safe Containers requires periodic owner examinations to keep units safety-approved for international transport. That approval lapses if maintenance records go stale, which is one reason documentation matters as much as the repair itself.

Rust, roof, floor, and door maintenance tasks

Surface rust is cosmetic: a rough, flaky patch that hasn’t broken through the steel. Structural rust has, and it needs escalation rather than a paint job. A quick test is tapping the area with a wrench. A dull thud usually means the metal is still sound; a hollow sound or visible flaking through to the other side means it’s time to call in repair.

Roof: Clear leaves and debris after storms, check seams and top rails for separation, and never let water pool, since standing water accelerates both rust and leaks.

Floor: Press on suspect boards with a boot heel. Plywood that’s soft, swollen, or smells of mildew needs replacement before the next load, not after.

Doors and gaskets: Wipe tracks clean of grit before lubricating hinges and locking bars with a silicone-based or marine-grade lubricant rather than household oil, which washes out fast. Replace gaskets once they crack, flatten, or no longer spring back after being pinched.

Condensation control: Keep vents clear so moist air can escape, and use desiccant packs in units storing sensitive goods. Positioning containers away from low ground where water collects reduces humidity buildup inside.

• Surface rust: clean, prime, and paint.
• Structural rust or a holed panel: escalate to a qualified repair technician.
• Soft or swollen floorboards: replace before next load.
• Flattened or cracked gaskets: replace, don’t patch.

Pro Tip: A five-minute roof clearing after every storm does more to prevent long-term rust than any annual touch-up coat.

Documentation, seal control, and maintenance records

A short, consistent log protects you during an audit and speeds up repair decisions. Each entry should capture details aligned with a comprehensive SPCC checklist to ensure environmental compliance alongside container maintenance.

1. Inspector name and date of inspection.
2. Container ID and location in the yard.
3. Seal number issued and confirmation it meets ISO 17712.
4. Defects found, with a one-line description of severity.
5. Corrective action taken and who performed it.
6. Return-to-service signoff from a supervisor.

Designate one or two staff as seal issuers so custody stays traceable. If a seal arrives broken or doesn’t match the logged number, isolate the container, record the discrepancy, and notify CBP when the shipment falls under that oversight. Keep records for at least a year and link each repair entry to its invoice, since that pairing makes warranty claims and future audits far simpler to document.

Conexwest support options: repair or replace

Not every defect calls for a shop visit. Non-structural issues like gasket wear, surface rust, or a failing lock are worth repairing on-site or through a fabrication service. When corner posts, cross members, or other load-bearing parts are compromised, replacement is usually the safer call. Conexwest offers shipping containers for sale, rental units, and customization services with delivery, so operators facing a structural failure have a direct path to a replacement unit rather than an extended downtime window.

Fitting the checklist into a single shift

The 7-point check fits best at the start of a shift, before the first container gets staged for loading. One trained checker runs the inspection and tags failures; a supervisor signs off on returns to service. A short weekly drill, walking a new hire through all seven points on a real unit, builds speed faster than a manual ever does. Spot-check a handful of signed-off units each week to catch shortcuts before they become habits.

— Conexwest

Sources

For official documentation, start with OSHA’s terminal handling standard and its container repair fact sheet, the CTPAT 7-point checklist, and the IMO’s Convention for Safe Containers page on safety approval.

• CTPAT 7 - Point Container Inspection Checklist
• 1917.71 - Terminals handling intermodal containers or roll-on roll-off operations. | Occupational Safety and Health Administration
• International Maritime Organization — Convention for Safe Containers (CSC)

FAQ

What is the 7-point check for CTPAT?

The CTPAT 7-point check covers the front wall, left side, right side, floor, ceiling or roof, inside and outside doors, and the outside or undercarriage of a container. It’s designed to confirm structural soundness and rule out concealment before a container is stuffed, as outlined in the CTPAT checklist.

What is included in a maintenance checklist?

A solid maintenance checklist covers door and gasket condition, roof and floor integrity, rust or corrosion, locking gear, seal verification, and ventilation. It should also capture documentation fields like inspector name, date, container ID, and corrective action taken.

Where do you find container inspection checklists?

Official templates are available through CBP’s CTPAT resources and OSHA’s published guidance on terminal and repair safety. Container providers and logistics operators also publish their own job aids based on these frameworks.

What is a QC checklist?

A quality control checklist for containers verifies that a unit meets condition standards before it’s released for use, covering structural integrity, weatherproofing, door function, and cleanliness. It’s typically used alongside the 7-point security check rather than replacing it.
